APC SURT3000XLI-CH Smart UPS RT 3000, ON-LINE,Tower/Rackmount 2U,Replacement battery cartridgeAPCRBC140,208/230V, 8x IEC C13+2x IEC jumper, USB and Serial communication, AVR, Graphic LCD,Network Card

APC Smart UPS ONLINE 3000VA-SURT3000XLI-CH

**Overview:**

- **Lead Time:** Typically in stock

- **Main Information:**

  - **Load Running Time:** 2700 Watts

  - **Minimum - Maximum Range:** 210 - 2700 Watts

  - **14 minutes 5 seconds**

  - **Maximum Used Capacity:** 100%

- **Main Input Voltage:** 230 V

  - **Other Input Voltage:** 220 V to 240 V

- **Main Output Voltage:** 230 V

  - **Other Output Voltage:** 220 V to 240 V

- **Rated Power:**

  - **Power (W):** 2700 W

  - **Power (VA):** 3000 VA

- **Input Connection Type:** BS1363A UK, IEC 60320 C20, Schuko CEE 7 / EU1-16P

- **Output Connection Type:**

  - 8 IEC 60320 C13

  - 2 IEC Jumpers

  - 2 IEC 60320 C19

- **Rack Units:** 3U

- **Cable Length:** 2.44 m

- **Cable Quantity:** 1

- **Battery Type:** Lead-acid battery

- **Included Accessories:**

  - Software CD

  - Smart-UPS RS232 Signal Cable

  - User Manual

**Battery and Runtime:**

- **Runtime:** View Runtime Graph

- **Pre-installed Batteries:** 2

- **Typical Recharge Time:** 2.5 hours

- **RBC™ Quantity:** 1

- **Other Parameters:**

  - Configurable for 220, 230, or 240 V output voltage

  - Battery Charge Voltage (W): 382 W rated

  - Battery Lifespan: 3–5 years

  - Venturi Pipe: APCRBC140

  - Automatically detectable, expandable delay time: 1

**General:**

- **Topology:** Double conversion online

- **Number of Power Module Free Slots:** 0

- **Number of Power Module Filled Slots:** 0

- **Redundant:** No

**Physical Parameters:**

- **Color:** Black

- **Height:** 43.2 cm

- **Width:** 13 cm

- **Depth:** 67.3 cm

- **Net Weight:** 54.55 kg

- **Installation Position:** Front

- **Mounting Preference:** Lower

- **Installation Type:** Rack-mounted with kit, Two-post mountable

- **USB Compatible:** No

**Input:**

- **Network Frequency:** 50/60 Hz +/- 5 Hz auto-sensing

- **Input Voltage Limit:** 160...280 V

**Output:**

- **Maximum Configurable Power in VA:** 3000 VA

- **Maximum Configurable Power (W):** 2700 W

- **Output Frequency (Synchronized with Main Frequency):** 50/60 Hz +/- 3 Hz user-adjustable +/- 0.1 synchronized with main frequency

- **Waveform Type:** Sine wave

- **Power Efficiency:** 91% (full load)

- **Harmonic Distortion:** Less than 3%

- **Crest Factor:** 3:1

- **Bypass Type:** Internal bypass (automatic and manual)

**Compliance:**

- **Product Certifications:**

  - BSMI

  - C-Tick

  - CE

  - CSA

  - GOST

  - JEON

  - VCCI

  - VDE

- **Compliance Standards:**

  - EN/IEC 62040-1:2019/A11:2021

  - EN/IEC 62040-2:2006/AC:2006

  - EN/IEC 62040-2:2018

**Environmental Conditions:**

- **Operating Temperature:** 0…40 °C

- **Relative Humidity:** 0…95%

- **Operating Altitude:** 0...10000 ft

- **Storage Temperature:** -15…45 °C

- **Storage Relative Humidity:** 0…95%

- **Storage Altitude:** 0.00…15240.00 m

- **Sound Level:** 55 dBA

- **Heat Dissipation:** 655 Btu/h

**Communication and Management:**

- **Empty Slots:** 1

- **Alarm:** Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm

- **Emergency Shutdown:** Yes

- **Surge Protection and Filtering:**

  - **Surge Suppression Energy:** 480 J

  - **Filter:** Multi-stage noise filtering complies with UL1449 standard

**Packaging Information:**

- **Unit Type of Package 1:** PCE

- **Number of Units in Package 1:** 1

- **Package 1 Height:** 34.7 cm

- **Package 1 Width:** 98 cm

- **Package 1 Length:** 60.3 cm

- **Package 1 Weight:** 63.64 kg

**Contract Warranty:**

- **Warranty Period:** 2 years maintenance or replacement within the first 2 years
